The dimensions of C36000 copper rods vary depending on the shape and processing technology:
Round rods
Diameter range: Common 1.5-100mm, some suppliers provide precision specifications from 0.0625 inches (about 1.5875mm) to 4.5 inches (about 114.3mm)
Length range: Generally 2500-6000mm, some standard lengths are 12 feet (about 3.66 meters)
Flat rods/rectangular rods
Typical dimensions are 15.88mm×3.18mm, other specifications can be customized.
Tolerance requirements: Diameter tolerance ranges from ±0.0013 inches to ±0.008 inches
Specific implementation depends on the standard.
International Standards
C36000 mainly follows the following standards:
ASTM B16: Standardizes chemical composition, mechanical properties and dimensional tolerances, requiring copper content of 60.0-63.0% and lead of 2.5-3.7%.
AMS 4610 and SAE J461: Supplementary material manufacturing and delivery requirements.
Other corresponding grades: such as JIS C3604, DIN CuZn39Pb3, etc., suitable for different countries/regions.
Main components:
Copper (Cu): 60.0%-63.0%
Zinc (Zn): As a balance, the content is about 32.5%-37.5%
Lead (Pb): 2.5%-3.7%, used to improve cutting performance
Iron (Fe): ≤0.35%
Other impurities (such as aluminum, phosphorus, sulfur, etc.): total ≤0.5%
Other trace components:
Aluminum (Al) ≤0.5%, used to strengthen the alloy
Sulfur (S), phosphorus (P), etc. ≤0.01%
Mechanical properties (by state)
Annealed state (O60)
Tensile strength: 330 MPa
Yield strength: 140 MPa
Elongation: 15-23%
Hardness: Brinell hardness (HB) about 80-90
Elastic modulus: 100 GPa
Shear strength: 210 MPa
Semi-hard state (H02)
Tensile strength: 360-395 MPa
Yield strength: 140-170 MPa
Elongation: 7-17%
Hardness: Brinell hardness (HB) about 90-100
Hard state (H04)
Tensile strength: 550 MPa
Yield strength: 310 MPa
Elongation: 4%
Hardness: Brinell hardness (HB) about 130
Other key properties
Fatigue strength: 135 MPa (hard state)
Impact toughness: Izod impact energy about 8 ft·lbf (11 J)
Shear modulus: 39 GPa
Poisson's ratio: 0.31-0.34
